Encoding images

In this example, we’ll learn how to encode an image tensor to JPEG or PNG using the JpegEncoder and PngEncoder classes.

Note

These encoders supersede the ones from torchvision.io: they are more robust and support more features. See Migrating from TorchVision to TorchCodec for a migration guide.

First, a bit of boilerplate: we’ll download an image from the web and define a plotting utility. You can ignore that part and jump right below to Encoding an image.

import requests
import torch

from torchcodec.decoders import decode_image

url = "https://raw.githubusercontent.com/meta-pytorch/torchcodec/refs/heads/main/docs/source/_static/thumbnails/pigeon_encoding.jpeg"
response = requests.get(url, headers={"User-Agent": ""})
if response.status_code != 200:
    raise RuntimeError(f"Failed to download image. {response.status_code = }.")

# The image to encode, a CHW uint8 tensor. It could come from anywhere (e.g. a
# model output); here we just decode one.
image = decode_image(response.content)


def plot(image: torch.Tensor):
    try:
        import matplotlib.pyplot as plt
        from torchvision.transforms.v2.functional import to_pil_image
    except ImportError:
        print("Cannot plot, please run `pip install torchvision matplotlib`")
        return

    pil_image = to_pil_image(image)
    fig = plt.figure(figsize=(pil_image.width / 100, pil_image.height / 100))
    ax = fig.add_axes([0, 0, 1, 1])
    ax.imshow(pil_image)
    ax.axis("off")

Encoding an image

Encoders expect a 3D uint8 tensor in CHW layout (1 or 3 channels), which is exactly what our image is:

print(f"{image.shape = }, {image.dtype = }")
plot(image)

image.shape = torch.Size([3, 288, 300]), image.dtype = torch.uint8

We instantiate a JpegEncoder with the image, and encode it. Three destinations are supported: a file with to_file(), a file-like object with to_file_like(), or a 1D uint8 tensor of raw bytes with to_tensor().

import io

from torchcodec.encoders import JpegEncoder

encoder = JpegEncoder(image)

encoder.to_file("image.jpg")  # to a file
encoder.to_file_like(io.BytesIO())  # to a file-like object
encoded = encoder.to_tensor()  # to a tensor

print(f"{encoded.shape = }, {encoded.dtype = }")

encoded.shape = torch.Size([12146]), encoded.dtype = torch.uint8

That’s it! We can decode the encoded bytes back to make sure everything worked:

from torchcodec.decoders import decode_jpeg

decoded = decode_jpeg(encoded)
print(f"{decoded.shape = }")
plot(decoded)

decoded.shape = torch.Size([3, 288, 300])

PngEncoder works exactly the same way, and PNG is lossless (unlike JPEG):

from torchcodec.encoders import PngEncoder

encoded = PngEncoder(image).to_tensor()
print(f"{encoded.shape = }")

encoded.shape = torch.Size([104350])

Both encoders support encoding options: JpegEncoder takes a quality (1-100), and PngEncoder takes a compression_level (0-9). For example, a lower JPEG quality yields a smaller output:

small = JpegEncoder(image).to_tensor(quality=10)
large = JpegEncoder(image).to_tensor(quality=95)
print(f"{small.numel() = }, {large.numel() = }")

small.numel() = 3824, large.numel() = 28251

Encoding JPEGs on GPU

JpegEncoder can encode directly on a CUDA device with nvJPEG: just pass it an image that already lives on the GPU, and the encoding happens there. Only 3-channel RGB images are supported on CUDA. With to_tensor, the encoded bytes stay on the GPU (call .cpu() to bring them back to the host).

from torchcodec.encoders import JpegEncoder

encoded = JpegEncoder(image.cuda()).to_tensor()  # encoded bytes on the GPU
# you can still use to_file and to_file_like, but the encoded bytes will
# be copied back to the CPU first.

PNG encoding is CPU-only.

Check the docstrings of the encoding methods to learn about the different encoding options.
